Blustream 2-Way HDMI2.0 4K 60Hz 4:4:4 Downscaler

SC12SP-V2

HDMI 4K HDCP 2.2 Splitter with In-built Down-scaler, Audio Breakout and EDID Management

Key Features

• Features 1 x HDMI input that is replicated to 2 x HDMI outputs
• Supports HDMI 2.0 18 Gbps specification including HDR
• Supports up to 4K UHD 60Hz 4:4:4
• HDMI output 2 supports 4K UHD video pass-through
• HDMI output 1 will down-scale the video input to the following formats:

- 1080p @24/25/30/50/60Hz* (for screens that do not support 4K)
- 4K @50/60Hz 4:2:0 (for screens that do not support full 4K 60Hz 4:4:4)

• Supports all known HDMI audio formats including Dolby TrueHD, Atmos and DTS-HD
• Master Audio transmission
• HDMI audio breakout to analogue L/R audio and coaxial digital outputs concurrently
• Advanced EDID management
• HDCP 2.2 support

* Frame rate will always match the input signal

Box Contents
1 x SC12SP-V2
1 x 5V/1A DC power supply
1 x Mounting kit
1 x Quick Reference Guide
